| ECO BLOCK Modular System Switchboard is designed to provide flexibility and |
| simple combination of various module size to accomodate various range, rating or size of switching parts to form a complete switchboard. |
| |
 |
The switchboard can be assembled to provide various form of internal separation from Form1 to Form 4 with front or rear connection features. |
|
The normal standard form for switching parts mounting is the fixed panel type. |
|
ECO BLOCK Line Plug-in type panel or demountable type panel provides the flexibility to conduct service, repair, maintenance or modification of individual panel without the need to switch off the supply of the whole switchboard. |
|
This is a vital and advantages feature for any industries that cannot afford to have interrupted power supply. |
|
| |
| |
 |
| 1 |
The main busbar system is located at the top of the switchboard.
At each shipping split, there is a split joint on the main busbar.
The main busbar is fully covered with ventilated metal covers through out the whole lenght of the switchboard.
Bolting holes are provided at both end of the busbar for future extension of the switchboard.
|
|
|
| |
